V7P loudspeaker Point sources High performance 3-way passive point source loudspeaker
- Components 2 x 10"/8"/3"
- Dispersion 75° x 40°
- SPLmax 140 dB
- Weight 33 kg / 75 lb
标题
Amplifier
The following specifications of power amplifiers can be used to drive AL90.
Recommended products
System data
Frequency response (-5 dB standard):59 Hz - 18kHz
Frequency response (-5 dB CUT mode):100 Hz - 18 kHz
Max. sound pressure1with D20/30D:137 dB with D40/D80/40D:140 dB
Cabinets per amplifier channel:2
Loudspeaker data
Configuration:Highperformance 3-way passive point source loudspeaker
Nominal impedance:8 Ω
Power handling capacity (RMS/peak 10 ms):500/2000 W
Nominal dispersion angle (h x v):75° x 40°
Components:2 x 10" LF driver with neodymium magnet 1 x 8" MF driver with neodymium magnet 1 x 3” exit compression driverPassive crossover network
Connections:2 x NLT4 F/M optional 2 x NL4 M
Dimensions / weight
Dimensions (H x W x D):700 x 308 x 466 mm 27.5 x 12 x 18.3"
Weight:33 kg 75 lb
