80W-100W Full Color Laser Light


Sale price
Laser power: 80W
Model: XHR-RGB80
Red wavelength: 638nm: 20W
Green wavelength: 520nm: 30W
Blue wavelength: 445nm: 30W
Operating voltage input: 90-250V-50/60hz (globally applicable range)
Output power: ≤1200W

    功率: 80W

      标题

      Amplifier

      The following specifications of power amplifiers can be used to drive AL90.

      Recommended products

      PRODUCT SPECIFICATIONS

      Laser power: 80W

      Model: XHR-RGB80

      Red wavelength: 638nm: 20W

      Green wavelength: 520nm: 30W

      Blue wavelength: 445nm: 30W

      Operating voltage input: 90-250V-50/60hz (globally applicable
      range)

      Output power: ≤1200W

      Laser module: Pure diode (NICHA)

      Laser divergence angle: <1.6mrad (full angle)

      Laser spot size: <6.5mm at the output port

      Modulation voltage: ≤100KHz

      Graphic scanning speed: DT30K-mirror

      Scanning angle: +/-30 degrees (60 degrees)

      Control method: Built-in single-chip microcomputer running
      program main control board, ILDA standard 25-pin connecting line/sound
      control/self-walking/DMX512/master-slave networking/built-in SD card with rich
      animation+line+text materials, and can be used in conjunction with American
      pangolin software FB4/FB3 maker and computer PC for synchronous use

      Waterproof rating: (IP rating) IP65

      Product size: 625543.5CM

      Product net weight: 75KG

      Working temperature range: -50℃~50℃ for
      normal use

      Application scenarios: Cultural tourism landscape
      engineering/outdoor landmarks/water curtain fountains/large-scale electronic
      music festivals/mountain advertising text, etc.
