A15 Focus Performance And Simplicity 2-Way Passive, 15"

Sale price
Max SPL 144 dB
Bandwidth 41 Hz- 20 KHz
Transducers LF : 1 x 15"
HF : 1 x 3"
Weight 35 kg / 77 lb
Directivity H: 70° / 90° / 110°
V: 10°



Model: A15 Focus
CONSTANT CURVATURE LINE SOURCE
CONSTANT CURVATURE LINE SOURCE
CONSTANT CURVATURE LINE SOURCE
L-VENTS
L-VENTS
Introduced for the laminar venting technology is a progressive vent design that drastically minimizes turbulence noise leading to an increase in output capability. All current LA-Proaudioinc loudspeaker enclosures with low-range capacities feature L-Vents.
DOSC
DOSC
Avec la technologie propriétaire de modelage de front d’onde (Wavefront Sculpture Technology, WST), le système LA-Proaudioinc V-DOSC a été le premier line array à fonctionner de manière cohérente sur toute la gamme des fréquences audibles. cette innovation majeure est au centre de tous les produits line source de LA-Proaudioinc, avec un WST précisément adapté à chaque élément.
PANFLEX
PANFLEX
Panflex offre la possibilité d'élargir ou de rétrécir le diagramme de rayonnement des sources en ligne grâce à des surfaces (L-Fins) réglables. Avec Panflex, l’utilisateur peut adapter le diagramme d’émission du système pour qu'il corresponde à la géométrie complexe de n'importe quelle configuration de public.

    标题

    Electroacoustic specs

    2-way passive constant curvature WST 10°
    amplified by LA4X / LA8 / LA12X

    Usable bandwidth (-10 dB):41 Hz – 20 kHz ([A15])

    Maximum SPL1:144 dB ([A15])

    Nominal directivity (-6 dB)

    Enclosure: 10°
    L-Fins: 110° / 70° symmetric , 90° asymmetric

    Transducers

    LF: 1 × 15″ cone drivers
    HF: 1 × 3″ diaphragm compression drivers

    Acoustical load

    LF: bass-reflex, L-Vents
    HF: DOSC waveguide, Panflex

    Nominal impedance:8 Ω

    Physical specs

    Connectors

    IN: 1 × 4-point speakON
    LINK: 1 × 4-point speakON

    Rigging and handling:Flush-fitting two-point rigging system
    1 handle, 8 corner stops and 2 ground runners

    Weight (net):35 kg / 77 lb

    Cabinet:Premium grade Baltic beech and birch plywood

    Front:Coated steel grill
    Acoustically neutral 3D fabric

    Rigging components:High grade steel with anti-corrosion coating

    Finish:Dark grey brown Pantone 426 C

    IP:IP55
