LA4X Amplified controller

Architecture 4 x 4
Output power 4 x 1000 W at 4 and 8 ohms
Power supply Universal SMPS with PFC
Inputs AVB, AES/EBU, Analog

Quantity:

Amplification and power supply
Amplification class	Class D
Output power, all channels loaded	4 x 1000 W at 4 ohms/ 4 x 1000 W at 8 ohms
Power supply model	Universal Switched Mode Power Supply (SMPS) with Power Factor Correction (PFC)
Mains rating	100 V - 240 V ±10%, 50-60 Hz

DSP
Digital Signal Processor (DSP)	SHARC 32-bit, floating point, 96 kHz sampling rate
I/O routing	Flexible 4x4 routing matrix
Per output channel	UBuilt-in EQ station with 8 IIR, 4 FIR linear phase EQ filters Array morphing, Air absorption compensation filters Internal IIR and FIR EQ algorithms L-DRIVE advanced system protection Output delay from 0 to 1000 ms

Technologies
Loudspeaker management	L-DRIVE advanced system protection

Latency
Standard latency (analog/digital inputs)	3.84 ms

Inputs
AVB	4 channels from 1 stream (of up to 8 channels)
AES/EBU	4 channels AES/EBU (2 x AES3) with SRC
Analog	4 channels
Connections	2 etherCON 1 Gb/s I/O+ control 4 female 3-pin XLR (2 x switching analog/AES3) 4 male 3-pin XLR links

Outputs
Loudspeaker connections	4 x SpeakON

Interface
Display/indicators	LCD and LED's
Navigation	Rotary encoder, power and mute keys

Control and monitoring
L-Acoustics remote control software	LA Network Manager
Third-party management solutions	Q-SYS® / Crestron® / Control4® / Savant®/ SNMP / Extron®

Operating conditions
Temperature	0º C / 32º F to +50º C / 122º F
