YQ-DE200

Rated voltage: AC100V～240V 50/60Hz
Bulb specification: 200W white LED
Rated life: 20000 hours, color temperature: 9000K
LED light circle: 29 LED high brightness three-in-one lamp beads, built-in a variety of running effect program, can be detached from the console master-slave synchronous operation
Beam angle: zoom 0 ° ~ 5 ° 64mm large diameter light, beam angle of 14 degrees
Color: with macro command function color plate: 7 colors + white full color / half-color / linear color variable speed two-way rainbow effect, built-in high-efficiency Hall devices
Pattern: 1 fixed gobo disk: 7 patterns + 6 glass patterns + white light, can be rotated at variable speed in both directions, with variable speed jitter effect, two-way variable speed flow effect, built-in high-efficiency Hall devices
Prism: 1 (6 + 12 double prism), can be stacked two-way variable speed rotation, with index function variable speed jitter effect
Focus: DMX linear focus, with auto focus function
Electronic strobe, 0.3 ~ 25 times / sec, can choose synchronous, asynchronous random strobe
Dimming: electronic dimming 0 ~ 100% linear adjustment, with a gamma curve dimming frequency 1.2K ~ 25K adjustable, with macro command dimming linear stable and smooth without flickering, using a stable constant current driver and power supply, suitable for video shooting
Rotation Angle: Horizontal 540 ° (16 bit precision scanning), vertical 270 ° (16 bit precision scanning) XY axis using high-speed mute motor drive, so that run faster and smoother, when the occurrence of false movement can be automatically returned to the position of the horizontal and vertical speed is adjustable; XY axis rotation function and take the function of the inverse; the use of optoelectronic high-precision positioning
Control mode: 22CH (standard) 1 kind of channel control mode, standard DMX512 protocol, RDM protocol.
Control interface: DMX512 interface (3-core / optional 5-core), power cord hand socket
Hibernation function: using advanced technology to realize the remote hibernation function, when the lamps and lanterns disconnect the signal automatically enter the hibernation state, so that the lamps and lanterns are more stable and safer
Display function: 1.77-inch LCD, bilingual menu, sensor failure display, temperature display.
Heat dissipation system: light aluminum radiator, fan intelligent monitoring technology
According to the temperature of the lamps and lanterns to automatically adjust the fan speed, built-in overheating protection intelligent system / intelligent temperature and noise balance module
Lamp body weight:
Protection level: IP20, optional rain cover protection level up to IP44
Packing: waterproof and shockproof air box or cardboard box Product Dimensions.
Packing size:42*30.5*30CM
Net weight:6.75KG
Gross weight:7.4KG
